ESP32-CAM WiFi Bluetooth Module

Product details of ESP32-CAM WiFi Bluetooth Module ESP32 Serial to WiFi ESP32 CAM Development Board 5V with Camera Module ESP32-CAM is a WIFI&Bluetooth dual-mode development board, which uses PCB on-board antennas and cores based on ESP32 chips. It can work independently as a minimum system ESP integrates WiFi, traditional Bluetooth, and BLE Beacon, with two high-performance 32-bit LX3 CPUs, 7-stage pipeline architecture, main frequency adjustment range 80MHz to 240MHz, on-chip sensor, Hall sensor, temperature sensor and so forth Fully compliant with WiFi 802.11b/g/n/e/i and Bluetooth 4.2 standards, it can be used as a master mode to build an independent network controller, or as a slave to other hosts MCUs to add networking capabilities to existing devices ESP32-CAM can be widely used in various IoT applications. It is suitable for home smart devices, industrial wireless control, wireless monitoring, QR wireless identification, wireless positioning system signals, and other IoT applications. It is an perfect solution for IoT applications Warm Tips:This product contains the OV2640 Camera Module. Up to 240MHz, up to 600 DMIPS Built-in 520 KB SRAM, external 4M PSRAM Supports interfaces such as UART/SPI/I2C/PWM/ADC/DAC Support OV2640 and OV7670 cameras with built-in flash Support for images WiFi upload Support TF card Support multiple sleep modes Embedded Lwip and FreeRTOS Support STA/AP/STA AP working mode Support Smart config/Airkiss one-click distribution network Support for serial local upgrade and remote firmware upgrade(FOTA) Support secondary development colour:black Material:PCB board Package Contents: 2 ESP32-CAM Module 2 Camera Module OV2640 2MP Only the above package content, other products are not included. Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.

Product details of ESP32-CAM WiFi Bluetooth Module ESP32 Serial to WiFi ESP32 CAM Development Board 5V with Camera Module

• ESP32-CAM is a WIFI&Bluetooth dual-mode development board, which uses PCB on-board antennas and cores based on ESP32 chips. It can work independently as a minimum system
• ESP integrates WiFi, traditional Bluetooth, and BLE Beacon, with two high-performance 32-bit LX3 CPUs, 7-stage pipeline architecture, main frequency adjustment range 80MHz to 240MHz, on-chip sensor, Hall sensor, temperature sensor and so forth
• Fully compliant with WiFi 802.11b/g/n/e/i and Bluetooth 4.2 standards, it can be used as a master mode to build an independent network controller, or as a slave to other hosts MCUs to add networking capabilities to existing devices
• ESP32-CAM can be widely used in various IoT applications. It is suitable for home smart devices, industrial wireless control, wireless monitoring, QR wireless identification, wireless positioning system signals, and other IoT applications. It is an perfect solution for IoT applications
• Warm Tips:This product contains the OV2640 Camera Module.
• Up to 240MHz, up to 600 DMIPS
• Built-in 520 KB SRAM, external 4M PSRAM
• Supports interfaces such as UART/SPI/I2C/PWM/ADC/DAC
• Support OV2640 and OV7670 cameras with built-in flash
• Support for images WiFi upload
• Support TF card
• Support multiple sleep modes
• Embedded Lwip and FreeRTOS
• Support STA/AP/STA AP working mode
• Support Smart config/Airkiss one-click distribution network
• Support for serial local upgrade and remote firmware upgrade(FOTA)
• Support secondary development
• colour:black
• Material:PCB board
• Package Contents:
• 2 * ESP32-CAM Module
• 2 * Camera Module OV2640 2MP
• Only the above package content, other products are not included.
• Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
