69% OffAutoDesk Inventor Tolerance Analysis 1 Year EDU License
License valid for 1 year. Download from AutoDesk™ website. Includes 24/7 support, 7 days a week. Best prices on the market with no external links.
Pay LKR 904.70 × 3 installments with KOKO Quick Overview
Product Specification
System Requirements Supported Operating Systems: Windows 11 Windows 10 Windows 8.1 Windows 7 Recommended Hardware: Processor: Multicore Intel Series or AMD equivalent (Xeon recommended for high-performance workflows) RAM: Minimum 4 GB (8 GB or more recommended for large assemblies) Hard Disk Space: 4 GB free disk space (more recommended for optimal performance) Use Cases Automotive, aerospace, and consumer product design High-precision mechanical assemblies GD&T validation for manufacturability Collaboration between design and manufacturing teams
License valid for 1 year. Download from AutoDesk™ website. Includes 24/7 support, 7 days a week. Best prices on the market with no external links.
Product Details
Key Benefits of Inventor Tolerance Analysis
- Predict and prevent assembly issues by identifying how part tolerances accumulate in your design.
- Reduce manufacturing risks and improve product quality by validating tolerance schemes early in the design process.
- Save time and reduce costs by minimizing trial-and-error adjustments and avoiding unnecessary redesigns.
- Improve cross-functional collaboration between design, manufacturing, and quality control teams through detailed reports.
Core Features of Inventor Tolerance Analysis
1. Linear Stack-Up Analysis
Analyze part tolerances in a single linear direction to evaluate geometric dimensioning and tolerancing (GD&T) in a 3D assembly.
2. Support for Multiple Analysis Methods
Choose from industry-standard methods:
- Worst-Case Analysis
- Statistical Analysis
- Root Sum of Squares (RSS) – a specific case of statistical analysis for more conservative results.
3. Comprehensive Statistical Metrics
View analysis outputs in formats like:
- Cpk (Process Capability Index)
- Sigma levels
- DPMO (Defects Per Million Opportunities)
- Yield
These help in understanding how robust your tolerances are under manufacturing variations.
4. Report Generation
Generate detailed, shareable reports that:
- Document the tolerance analysis process
- Provide metrics and visuals
- Support cost-control and quality assurance initiatives
Useful for communication with manufacturing engineers, quality teams, and stakeholders.
